Chongqing Gasoline Powerful Tiller by Gear Driven with Compact Size

How about assembly line? Firstly,assemble the shift gearbox; Secondly,assemble the walking box; Thirdly,assemble the chasis; Fourthly,assemble gasoline engine and handle bar to the farm machinery; Fifthly,assemble the wheel of tiller machinery. What is the process of packing? First,put farm...

Send Inquiry
Product Details

Tiller Model No.

1WG4.0-95FQ-ZC

Engine Specification

Model

170F/P

Bore*Stroke

70 * 55

Power

Max: 7HP / Rated:5.6HP

Type

1 Cylinder , 4 Stoke , Air Cooling

Fuel Capacity

3.6 Liter

Fuel Type

Gasoline

Fuel Consumption

≤340 Gram / Kw.Hour

Lube Capacity

0.6 Liter

Lube Type

SAE10W-30

Starting System

Manual Pull

Tiller Specification

Max. Power

4Kw /3600KPM

Lube Capacity

Gear Box: 0.95 Liter

Lube Type

SAE10W-30

Working Width

950 mm

Working Depth

≥100 mm

Gear Shifting

2 forward: Fast and Slow / 1 Reverse / Neutral

Transmission

Gear

Packing Details

Carton with Bracket

Packing Size

850*450*750 mm

N.W. / G.W.

62KG / 85KG

Standard Configurations

400-8 Travel Tires x 2pcs,

Φ 23 Dry Blades (24pcs of blades in total-3+1 type),

Handle Vertical Adjustment

How about assembly line?

Firstly,assemble the shift gearbox;
Secondly,assemble the walking box;
Thirdly,assemble the chasis;
Fourthly,assemble gasoline engine and handle bar to the farm machinery;
Fifthly,assemble the wheel of tiller machinery.

What is the process of packing?
First,put farm machinery into the carton box with iron frame;
Second,close the carton ,and then bundled it with woven belt;
Third , with the forklift into the container;
Fourth,when all farm machinery in the container,waiting for departure.
