5HP Garden Power Tiller/Cultivator with 173f Diesel Engine, Fd900c

5HP Garden Power Tiller/Cultivator with 173f Diesel Engine, Fd900c

It is mainly suitable for using in narrow land, terraced fields in mountain area, vegetable garden, orchard and greenhouse. It features compact construction, easy and flexible handling, light weight, reliable operation, convenient maintenance as well as good trafficability. 1. Its small-size,...
Send Inquiry
Product Introduction

With responsible good quality method, good status and excellent client services, the series of solutions produced by our company are exported to lots of countries and regions for bracket cultivator, farm rototiller, 4 KW tiller. We're willing to cooperate with business friends from at home and abroad, to create a great future. In recent years, we have continued to develop in the fierce market competition. With the support of our customers, our products are sold all over the world and are deeply trusted by customers. We have a vigorous sales and comprehensive technical team.

Production Specifications


Tiller Model No.

1WG6.5-135FQ-Z

Engine Specification

Model

188F/P

Bore*Stroke

88 * 64

Power

Max: 13HP / Rated:11.5HP

Type

1 Cylinder , 4 Stoke , Air Cooling

Fuel Capacity

6 Liter

Fuel Type

Gasoline

Fuel Consumption

≤340 Gram / Kw.Hour

Lube Capacity

1.1 Liter

Lube Type

SAE10W-30

Starting System

Manual Pull

Tiller Specification

Max. Power

6.5Kw /3600KPM

Lube Capacity

Gear Box: 2.5 Liter

Lube Type

SAE10W-30

Working Width

1350 mm

Working Depth

≥100 mm

Gear Shifting

2 forward: Fast and Slow / 1 Reverse / Neutral

Transmission

Gear

Packing Details

Carton with Bracket

Packing Size

910*570*780 mm

N.W. / G.W.

115KG / 126KG

Standard Configurations

400-8 Travel Tires x 2pcs,

Φ 32 Dry Blades (32pcs of blades in total-3+1 type)


Production Introduction


Rotary Weeder is principally suitable for including in close land, terraced fields in mountain district, vegetable nursery, estate and nursery. It features insignificant turn of events, straightforward and versatile managing, light weight, strong action, beneficial upkeep as well as incredible sellability.


1. Its little size, light-weight. Its force is strong and significant. Especially, it applies in restricted sections, yard of mountain district, tea farm, normal item woods, sheds, and so forth.


2. Lit handle, Gasoline Cultivator moreover can work as over-load grasp. It can shield over weight and use safely.


3. The handles can turn 360°horizontally and oversee tap and down with four grades.


4. Its essential farm equipment are all in accessibility. With relating devices, Gasoline Cultivator can grasp numerous capacities, for instance, weeding. breaking soil, making wrinkles, hilling soil, watering, showering pesticide, wrinkling.


5. Since the key trained professional and unfortunate behavior pattern engineer take parting quick association framework. it is incredibly easy to change them.


6. The track and wrinkle sharp edge can be turned broadness with essential.


7. This little turning furrowing machine arranged a little diesel or gas engine, 13 hp more grounded power. Reasonable development, low use, high working viability and top long use life make it hot arrangement and welcome by the clients all over.


8. Agricultural Rotary Weeder by and large use in the fields, mountains, uneven area of paddy field, dry and vegetable nurseries, especially, Specially sensible for mountain decks, little piece of farmland.


Additional Details


It is flawlessly fit so well in manor, farm field, and green house, the hand rail can be pivoting at 90 degree everywhere, 270 degree using any and all means around, transmission system is consistent, force is colossal, started by pulling, and resistance shaft significance can be changed, refined and it are perfect to weed results. Movement is so fundamental.

tiller company

wanggeng tiller company


Our solutions are broadly acknowledged and dependable by users and may meet consistently developing economic and social requires for 5HP Garden Power Tiller/Cultivator with 173f Diesel Engine, Fd900c. Our factory has established a long-term and effective cooperative relationship with customers based on the corporate philosophy of 'quality first, sincere service'. The company's employees forge ahead and make concerted efforts to develop new technologies and new products in line with market demand and development.
